SRP |
₱88,995 |
₱124,295 |
₱159,495 |
₱172,695 |
₱174,695 |
| Indoor Unit |
KV24CM-ARF21C2 |
KV36CM-ARF21D |
KV48CM-ARF21C |
KV60CM-ARF21D |
KV60CM-ARF21D |
|
Outdoor Unit |
KV24ODU-ARF21C2 |
KV36ODU-ARF21D |
KV48ODU-ARF21C |
KV60ODU-ARF21D |
KV60ODU-CRF21D |
| Cooling Capacity (Min-Max) |
TR |
2.0 |
3.0 |
4.0 |
5.0 |
5.0 |
| BTU/Hr |
25,100 |
36,000 (9,970-37,300) |
48,000 |
55,000 (17,900-56,490) |
55,000 (17,900-56,490) |
| kJ/Hr |
26,481 |
37,980 (10,518-39,352) |
50,640 |
58,025 |
58,025 |
| Power Supply |
V/Hz/Ph |
230/60/1 |
230/60/1 |
230/60/1 |
230/60/1 |
230/60/3 |
| Rated Power (Min-Max) |
W |
1,895 |
3,600 (850-4,350) |
4,200 |
5,760 (1,330-6,900) |
5,760 (1,330-6,900) |
| Rated Current (Min-Max) |
A |
10.1 |
16 (3.61-19.1) |
24.7 |
26 (5.7-30) |
15.4 (5.7-30) |
| EER |
BTU/W-Hr |
13.30 |
10.00 |
11.40 |
9.60 |
9.55 |
|
kJ/W-Hr |
13.97 |
10.60 |
12.10 |
10.10 |
10.07 |
| CSPF |
|
– |
4.71 |
– |
4.8 |
5.0 |
| Star Rating |
|
– |
««««« |
– |
««««« |
««««« |
| Refrigerant |
|
R410A |
R410A |
R410A |
R410A |
R410A |
| Ambient Temperature (Min-Max) |
°C |
17-32 |
17-32 |
17-32 |
17-32 |
17-32 |
| Operation Temperature (Min-Max) |
°C |
17-30 |
17-30 |
17-30 |
17-30 |
17-30 |
| Applicable Area (Unloaded Space) |
SQM |
25-42 |
38-63 |
48-80 |
60-100 |
60-100 |
| Indoor Airflow Volume (Hi/Mi/Lo) |
CMH |
1,290/-/- |
1,600/1,450/1,250 |
2,407/-/- |
2,180/1,915/1,635 |
2,180/1,915/1,635 |
| Indoor Noise Level (Hi/Mi/Lo) |
dB(A) |
-/-/40 |
50/47/43 |
-/-/51.1 |
54/51/48 |
54/51/48 |
| Indoor |
|
|
|
|
|
|
| Unit Dimension (W×D×H) |
mm |
1,068×675×235 |
1,285×675×235 |
1,650×675×235 |
1,650×675×235 |
1,650×675×235 |
| Packaging Dimension (W×D×H) |
mm |
1,145×755×318 |
1,360×755×318 |
1,725×755×313 |
1,725×755×318 |
1,725×755×318 |
| Unit Weight (Net/Gross) |
Kg |
26.5/31.4 |
32.1/37.6 |
38.7/45.2 |
41.7 / 48.3 |
41.7 / 48.3 |
| Outdoor |
|
|
|
|
|
|
| Unit Dimension (W×D×H) |
mm |
946×410×810 |
946×420×810 |
952×415×1,333 |
952×415×1,333 |
952×415×1,333 |
| Packaging Dimension (W×D×H) |
mm |
1,090×500×885 |
1,090×500×885 |
1,095×495×1,480 |
1,095×495×1,480 |
1,095×495×1,480 |
| Unit Weight (Net/Gross) |
Kg |
64/69 |
54.1/59.1 |
95/108 |
91.9/106 |
91.9/106 |
| Piping Connections |
|
|
|
|
|
|
| Liquid Pipe Size (Diameter) |
mm (in) |
Ø9.52 (Ø3/8) |
Ø9.52 (Ø3/8) |
Ø9.52 (Ø3/8) |
Ø9.52 (Ø3/8) |
Ø9.52 (Ø3/8) |
| Gas Pipe Size (Diameter) |
mm (in) |
Ø15.9 (Ø5/8) |
Ø15.9 (Ø5/8) |
Ø19.05 (Ø3/4) |
Ø19.05 (Ø3/4) |
Ø19.05 (Ø3/4) |
| Max. Refrigerant Pipe Length |
m |
50 |
30 |
50 |
50 |
50 |
| Max. Difference in Level |
m |
25 |
20 |
30 |
30 |
30 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| (1) The above data for KV36CM-ARF21D & KV60CM-ARF21D was based on cooling conditions: Indoor air temperature 27°C DB 19°C WB, Outdoor air temperature 35°C DB 24°C WB. |
| (2) The above data for KV24CM-ARF21C2 & KV48ODU-ARF21C was based on cooling conditions: Indoor air temperature 27°C DB 19°C WB, Outdoor air temperature 35°C DB 27°C WB. |
| (2) Prices and specifications are subject to change without prior notice for continuous product improvement. |
|
|
| (3) Koppel is a registered trademark of Koppel Inc. |
|
|
|
|
