| Specification | Remote | KWR-06R4B | KWR-09R4B | KWR-12R4B |
|---|---|---|---|---|
| Cooling Capacity | HP | 0.6 | 1.0 | 1.5 |
| BTU/Hr | 6,000 | 9,400 | 12,700 | |
| kJ/Hr | 6,330 | 9,917 | 13,399 | |
| Power Supply | V/Ph/Hz | 230 /60 |
230 /60 |
230 /60 |
| Rated Power | W | 550 | 855 | 1,150 |
| Rated Current | A | 2.4 | 3.75 | 5.25 |
| EER | BTU/W-Hr | 10.9 | 11.0 | 11.3 |
| kJ/W-Hr | 11.5 | 11.6 | 11.9 | |
| CSPF | 3.4 | 3.42 | 3.44 | |
| Star Rating | ★★ | ★★ | ★★★ | |
| Refrigerant | R32 | R32 | R32 | |
| Ambient Temperature (min-max) | °C | 17-30 | 17-30 | 17-30 |
| Applicable Area (Unloaded Space) | SQM | 8-11 | 12-18 | 16-23 |
| Airflow Volume (Hi/Mi/Low) | CMH | 255/220/197 | 340/295/264 | 540/485/430 |
| Noise Level (Hi/Mi/Low) | dB(A) | 58/56/54 | 59/55/53 | 60/58.5/56 |
| Unit | ||||
| Unit Dimension (W×D×H) | mm | 415×340×305 | 480×410×345 | 495×555×378 |
| Packaging Dimension (W×D×H) | mm | 452×388×367 | 561×455×380 | 557×586×430 |
| Unit Weight (Net/Gross) | kg | 16.53/17.91 | 21.14/23.10 | 29.26/31.97 |
Download Brochures
Download Manuals
Frequently Asked Questions
You can buy Koppel air conditioners in major appliance retail stores or through our accredited dealers nationwide. You can also contact us directly via our sales office (02) 8823-8883 or by emailing us at sales@koppel.ph.
Non-Inverter Window Type AC: One (1) year on parts and labor, five (5) years on compressor from date of purchase.
Inverter Window Type AC: One (1) year on other parts, labor and consumables, three (3) years on PCB and ten (10) years on compressor from date of purchase. Effective May 15, 2024. Terms and conditions apply.
Non-Inverter Wall Mounted Split Type AC: One (1) year from start up date or 18 months from purchase, whichever is earlier on parts and labor. Five (5) years from date of purchase on the compressor.
Inverter Wall Mounted Split Type AC: One (1) year on other parts, labor and consumables, three (3) years on PCB and ten (10) years on compressor from date of purchase. Effective May 15, 2024. Terms and conditions apply.
Light Commercial Products: One (1) year from start up date or 18 months from purchase, whichever is earlier on parts, labor and compressor.
To obtain service within the warranty period, please contact the Koppel Customer Service Hotline at (02) 8823-8883 + Local Numbers 316, 317, 318, 319, 320, 321 or 322.
For the indoor unit, the model and serial number can be found on a sticker label located on the right side of the front panel when facing the unit.
For the outdoor unit, it is located on the upper right side of the panel, when facing the unit.
Up to 50% savings as compared to a non-inverter unit.
Inverter technology uses a variable speed compressor which automatically adjusts A/C capacity depending on the room's heat load. Using an inverter vs. a non-inverter can significantly reduce your electricity costs by up to 50%.
We have over 200 Koppel Accredited Service Centers nationwide. Kindly note that not all installers are authorized service centers and vice versa.
Any of our Authorized Installers can do it for you. Please visit our website for the full list of authorized installers.
The final cost will vary depending on the extent of damage on your unit and the scope of work that will be done. This will also be subject to the cost of the replacement part/s, if applicable.
You may contact our Koppel Customer Service Hotline at (02) 8823-8883 + Local Numbers.
For Parts Inquiry: Local 310 or 313
For Customer Support: Local 316, 317, 318, 319, 320, 321 or 322
Proper maintenance is essential. Always have your air conditioner cleaned and checked for any unusual noise and leaks. It is advised to have your air conditioner undergo preventive maintenance twice a year. You may avail your free one (1) preventive maintenance and one (1) general cleaning during the one year warranty period.
