| Specification | Remote | KV07WR-ARF31B | KV09WR-ARF31B | KV12WR-ARF31B |
|---|---|---|---|---|
| Cooling Capacity | HP | 0.75 | 1.0 | 1.5 |
| BTU/Hr | 7,230 | 9,325 | 11,750 | |
| kJ/Hr | 7,628 | 9,838 | 12,396 | |
| Power Supply | V/Ph/Hz | 230 /60 |
230 /60 |
230 /60 |
| Rated Power | W | 667 | 803 | 1,300 |
| Rated Current | A | 3.0 | 3.50 | 5.70 |
| EER | BTU/W-Hr | 10.84 | 11.61 | 9.04 |
| kJ/W-Hr | 11.44 | 12.25 | 9.54 | |
| CSPF | 4.52 | 4.82 | 4.30 | |
| Star Rating | ★★★★★ | ★★★★★ | ★★★★★ | |
| Refrigerant | R32 | R32 | R32 | |
| Operation Temperature (Min-Max) | °C | 16-30 | 16-30 | 16-30 |
| Applicable Area (Unloaded Space) | SQM | 9-14 | 9-18 | 16-23 |
| Airflow Volume Hi/Mi/Low | CMH | 355/315/285 | 355/315/290 | 387/340/313 |
| Noise Level Hi/Mi/Low | dB(A) | 56/53/51 | 57/54/52 | 59/55/53 |
| Unit | ||||
| Unit Dimension (W×D×H) | mm | 471×482×345 | 471×482×345 | 471×482×345 |
| Packaging Dimension (W×D×H) | mm | 574×537×361 | 574×537×361 | 574×537×361 |
| Unit Weight (Net/Gross) | kg | 19.3/21.3 | 20.3/22.1 | 20.7/22.7 |
