| Specification | Remote | KWR-06R4B | KWR-09R4B | KWR-12R4B |
|---|---|---|---|---|
| Cooling Capacity | HP | 0.6 | 1.0 | 1.5 |
| BTU/Hr | 6,000 | 9,400 | 12,700 | |
| kJ/Hr | 6,330 | 9,917 | 13,399 | |
| Power Supply | V/Ph/Hz | 230 /60 |
230 /60 |
230 /60 |
| Rated Power | W | 550 | 855 | 1,150 |
| Rated Current | A | 2.4 | 3.75 | 5.25 |
| EER | BTU/W-Hr | 10.9 | 11.0 | 11.3 |
| kJ/W-Hr | 11.5 | 11.6 | 11.9 | |
| CSPF | 3.4 | 3.42 | 3.44 | |
| Star Rating | ★★ | ★★ | ★★★ | |
| Refrigerant | R32 | R32 | R32 | |
| Ambient Temperature (min-max) | °C | 17-30 | 17-30 | 17-30 |
| Applicable Area (Unloaded Space) | SQM | 8-11 | 12-18 | 16-23 |
| Airflow Volume (Hi/Mi/Low) | CMH | 255/220/197 | 340/295/264 | 540/485/430 |
| Noise Level (Hi/Mi/Low) | dB(A) | 58/56/54 | 59/55/53 | 60/58.5/56 |
| Unit | ||||
| Unit Dimension (W×D×H) | mm | 415×340×305 | 480×410×345 | 495×555×378 |
| Packaging Dimension (W×D×H) | mm | 452×388×367 | 561×455×380 | 557×586×430 |
| Unit Weight (Net/Gross) | kg | 16.53/17.91 | 21.14/23.10 | 29.26/31.97 |
