| Specification | indoor unit |
KSDV-120CHW KSDV-120CHW/A |
|---|---|---|
| Performance | ||
| Nominal Cooling Capacity | BTU/h | 120,000 |
| KJ/h | 126,600 | |
| Water Flow | L/S | 1.5 |
| Motor HP | HP | 2 |
| Rated External Static Pressure | Pa | 175 |
| Power Supply | V/Ph/Hz | 230V/ 3 / 60 |
| Blower Size (Centrifugal DWDI) | 15"x15" SINGLE | |
| Nominal Air Flow | m3/h (CFM) | 6,800 (4,000) |
| Unit | ||
| Dimension (WxDxH) | mm | 1,068 x 799.5 x 1,687.5 |
| Weight | kg | 227 |
| Pipe Connection Diameter | mm (inch) | 34.925 (1 3/8) |
