| Specification | Unit | KUD-60C | KUD-90C | KUD-120DC | KUD-120C | KUD-180DC |
|---|---|---|---|---|---|---|
| Cooling Capacity | TR | 5.0 | 7.5 | 10.0 | 10.0 | 15.0 |
| BTU/Hr | 60,000 | 90,000 | 120,000 | 120,000 | 180,000 | |
| kJ/Hr | 63,300 | 94,950 | 126,607 | 126,607 | 189,910 | |
| Power Supply | V/Ph/Hz | 230/3 /60 |
230/3 /60 |
230/3 /60 |
230/3 /60 |
230/3 /60 |
| Rated Power | W | 6,900 | 9,710 | 12,800 | 12,800 | 21,925 |
| Rated Current | A | 23.00 | 27.70 | 35.00 | 35.00 | 64.00 |
| EER | BTU/W-Hr | 8.70 | 9.28 | 9.38 | 9.38 | 8.22 |
| kJ/W-Hr | 9.17 | 9.79 | 9.90 | 9.90 | 8.67 | |
| Refrigerant | R410A | R410A | R410A | R410A | R410A | |
| Operation Temperature (Min-Max) | °C | 17-30 | 17-30 | 17-30 | 17-30 | 17-30 |
| Applicable Area (Unloaded Space) | SQM | 70-110 | 105-165 | 140-220 | 140-220 | 210-330 |
| Airflow Volume (Hi) | CMH | 3,700 | 6,200 | 6,392 | 6,392 | 11,663 |
| Overall Unit Dimension (W×D×H) | mm | 1,188×864×1,835 | 1,369.5×1,014×2,077.5 | 1,378×979.5×1,958 | 1,378×979.5×1,958 | 1,727×974.5×2,213 |
| Packaging Dimension (W×D×H) | mm | N/A | N/A | N/A | N/A | N/A |
| Unit Weight (Net/Gross) | Kg | 336 | 422 | 640 | 640 | 844 |
| A. Evaporator Section | ||||||
| Rated External Static Pressure | Pa | 75 | 125 | 175 | 175 | 250 |
| Motor Rating | hp | 1 | 2 | 2 | 2 | 3 |
| Blower Size (Centrifugal DWDI) | In | 12 x 12 (Single) | 15 x 15 (Single) | 12 x 12 (Double) | 12 x 12 (Double) | 12 x 12 (Double) |
| B. Condenser Section | ||||||
| Compressor Type | -- | Scroll | Scroll | Scroll | Scroll | Scroll |
| Number of Compressor | -- | 1 | 1 | 2 | 1 | 2 |
| Motor Rating | hp | 2 | 2 | 3 | 3 | 5 |
| Blower Size (Centrifugal DWDI) | In (Sets) | 10 x 10 (Double) | 12 x 12 (Double) | 12 x 12 (Double) | 12 x 12 (Double) | 15 x 15 (Double) |
| Piping Connections | ||||||
| Liquid Pipe Size (Diameter) | mm (In) | Ø12.7 (Ø1/2) | Ø15.875 (Ø5/8) | Ø12.7 (Ø1/2) | Ø15.875 (Ø5/8) | Ø15.875 (Ø5/8) |
| Gas Pipe Size (Diameter) | mm (In) | Ø22.225 (Ø7/8) | Ø22.225 (Ø11/8) | Ø22.225 (Ø7/8) | Ø28.575 (Ø11/8) | Ø28.575 (Ø11/8) |
| Max. Refrigerant Pipe Length | m | N/A | N/A | N/A | N/A | N/A |
| Max. Difference in Level | m | N/A | N/A | N/A | N/A | N/A |
