| Specification |
Indoor Unit Outdoor Unit |
KV09WM-ARF32A KV09OD-ARF32A |
KV12WM-ARF32A KV12OD-ARF32A |
KV18WM-ARF32A KV18OD-ARF32A |
KV24WM-ARF32A KV24OD-ARF32A |
|---|---|---|---|---|---|
| Cooling Capacity | HP | 1.0 | 1.5 | 2.0 | 2.5 |
| BTU/Hr | 9,800 (2,047 9,800) |
12,500 (4,095 12,500) |
19,000 (4,436 19,000) |
22,800 (6,142 22,800) |
|
| kJ/Hr | 10,339 (2,160 10,339) |
13,188 (4,320 13,188) |
20,045 (4,680 20,045) |
24,054 (6,480 24,054) |
|
| Power Supply | V/Ph/Hz | 230 /60 |
230 /60 |
230 /60 |
230 /60 |
| Rated Power | W | 995 | 1,324 | 1,772 | 2,450 |
| Rated Current | A | 4.55 | 6.0 | 8.0 | 10.65 |
| EER | BTU/W-Hr | 9.85 | 9.44 | 10.72 | 9.31 |
| kJ/W-Hr | 10.39 | 9.96 | 11.31 | 9.82 | |
| CSPF | 4.81 | 4.72 | 5.57 | 4.70 | |
| Star Rating | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | |
| Refrigerant | R32 | R32 | R32 | R32 | |
| Operation Temperature (Min-Max) | °C | 16-32 | 16-32 | 16-32 | 16-32 |
| Applicable Area (Unloaded Space) | SQM | 12-18 | 16-23 | 24-35 | 29-43 |
| Airflow Volume (Turbo/Hi/Mi/Lo) | CMH | 660/576/525/475 | 600/550/525/500 | 950/800/700/600 | 1,300/1,100/1,010/870 |
| Noise Level | dB(A) | 41 | 42 | 47 | 51 |
| Indoor | |||||
| Unit Dimension (W×D×H) | mm | 760×201×300 | 760×201×300 | 955×226×320 | 1,080×230×330 |
| Packaging Dimension (W×D×H) | mm | 831×371×282 | 831×371×282 | 1,070×385×312 | 1,210×400×327 |
| Unit Weight (Net/Gross) | kg | 7.5/10.0 | 7.5/10.0 | 11.5/14.5 | 13.0/17.0 |
| Outdoor | |||||
| Unit Dimension (W×D×H) | mm | 745×245×455 | 745×245×455 | 810×270×540 | 930×320×655 |
| Packaging Dimension (W×D×H) | mm | 760×305×510 | 760×305×510 | 825×326×595 | 945×400×715 |
| Unit Weight (Net/Gross) | kg | 16.0/18.5 | 16/18.5 | 21.5/25.0 | 28.5/33.0 |
| Piping Connections | |||||
| Liquid Pipe Size (Diameter) | mm (in) | Ø6.35 (1/4) | Ø6.35 (1/4) | Ø6.35 (1/4) | Ø6.35 (1/4) |
| Gas Pipe Size (Diameter) | mm (in) | Ø9.52 (3/8) | Ø9.52 (3/8) | Ø12.7 (1/2) | Ø12.7 (1/2) |
| Max. Refrigerant Pipe Length | m | 30 | 30 | 30 | 30 |
| Max. Difference in Level | m | 10 | 10 | 10 | 10 |
