| Specification |
Indoor Unit Outdoor Unit |
KFM-90E0C KPC-90IV0C/KPC-90IV0JC |
KFM-120E0C KPC-120IV0C |
KFMD-120E0C KPC-120IV0D0C |
KFMD-120E0C 2x KPC-60IH0BC/2x KPC-60IH0JBC |
KFMD-120E0C 2x KPC-60IV0BC/2x KPC-60IV0JBC |
|---|---|---|---|---|---|---|
| Cooling Capacity | TR | 7.5 | 10.0 | 10.0 | 10.0 | 10.0 |
| BTU/Hr | 90,000 | 120,000 | 120,000 | 120,000 | 120,000 | |
| kJ/Hr | 94,950 | 126,600 | 126,600 | 126,600 | 126,600 | |
| Power Supply | V/Ph/Hz | 230/3 /60 |
230/3 /60 |
230/3 /60 |
230/3 /60 |
230/3 /60 |
| Rated Power | W | 9,300 | 12,800 | 12,800 | 12,800 | 12,800 |
| Rated Current | A | 25.40 | 35.0 | 35.0 | 35.0 | 35.0 |
| EER | BTU/W-Hr | 9.68 | 9.38 | 9.38 | 9.38 | 9.38 |
| kJ/W-Hr | 10.21 | 9.89 | 9.89 | 9.89 | 9.89 | |
| Refrigerant | R410A | R410A | R410A | R410A | R410A | |
| Operation Temperature (Min-Max) | °C | 17-30 | 17-30 | 17-30 | 17-30 | 17-30 |
| Applicable Area (Unloaded Space) | SQM | 105-165 | 140-220 | 140-220 | 140-220 | 140-220 |
| Airflow Volume (Hi) | CMH | 3,900 | 5,500 | 5,400 | 5,400 | 5,400 |
| Noise Level (Low) | dB(A) | 60 | 65 | 65 | 65 | 65 |
| Indoor | ||||||
| Unit Dimension (W×D×H) | mm | 855×462×1,909 | 1,124×534×2,072 | 1,124×534×2,072 | 1,124×534×2,072 | 1,124×534×2,072 |
| Packaging Dimension (W×D×H) | mm | 944×550×1,980 | 1,175×580×2,097 | 1,175×580×2,097 | 1,175×580×2,097 | 1,175×580×2,097 |
| Unit Weight (Net/Gross) | kg | 101/115 | 203/212 | 203/212 | 203/212 | 203/212 |
| Outdoor | ||||||
| Unit Dimension (W×D×H) | mm | 810×810×783 | 1,000×1,000×983 | 1,000×1,000×983 | (936×355×1,268)/unit | (810×810×727)/unit |
| Packaging Dimension (W×D×H) | mm | 865×865×753 | N/A | N/A | (1,087×457×1,300)/unit | (865×865×690)/unit |
| Unit Weight (Net/Gross) | kg | 98/102 | 173 | 205 | (110/115)/unit | (92/96)/unit |
| Piping Connections | ||||||
| Liquid Pipe Size (Diameter) | mm (in) | Ø15.88 (Ø5/8) | Ø19.05 (Ø3/4) | Ø12.7 (Ø1/2) | Ø12.7 (Ø1/2) | Ø12.7 (Ø1/2) |
| Gas Pipe Size (Diameter) | mm (in) | Ø28.58 (Ø11/8) | Ø28.58 (Ø11/8) | Ø22.23 (Ø7/8) | Ø22.23 (Ø7/8) | Ø22.23 (Ø7/8) |
| Max. Refrigerant Pipe Length | m | 30/50 | 50 | 50 | 30/50 | 30/50 |
| Max. Difference in Level | m | 8 | 8 | 8 | 8 | 8 |
