| Specification | Indoor Unit |
KCM-18CHW KCM-18CHW/W |
KCM-24CHW KCM-24CHW/W |
KCM-36CHW KCM-36CHW/W |
KCM-60CHW KCM-60CHW/W |
|---|---|---|---|---|---|
| Performance | |||||
| Cooling Capacity | BTU/h | 18,000 | 24,000 | 36,000 | 60,000 |
| KJ/h | 18,990 | 25,320 | 37,980 | 63,300 | |
| Water Flow | L/S | 0.23 | 0.3 | 0.45 | 0.75 |
| Air Flow | m3/h (CFM) | 1,100 (647) | 1,100 (647) | 1,500 (882) | 2,400 (1,411) |
| Sound Level | dB(A) | 42 | 42 | 45 | 52 |
| Running Current | Amps | 1 | 1 | 2 | 2 |
| Rated External Static Pressure | Pa | 0 | 0 | 0 | 0 |
| Power Supply | V/Ph/Hz | 230V / 60 |
230V / 60 |
230V / 60 |
230V/ 3 / 60 |
| Unit | |||||
| Dimension (WxDxH) | mm | 1,007 x 670 x 271 | 1,007 x 670 x 271 | 1,402 x 670 x 271 | 1,794 x 670 x 271 |
| Packaging Dimension (WxDxH) | mm | 1,067 x 737 x 341 | 1,067 x 737 x 341 | 1,462 x 787 x 349 | 1,854 x 751 x 363 |
| Weight (Net/Gross) | kg | 48 / 54 | 48 / 54 | 66 / 72 | 74 / 80 |
| Pipe Connection Diameter | mm (inch) | 19.05 (3/4) | 19.05 (3/4) | 22.225 (7/8) | 28.575 (1 1/8) |
