| Specification | Indoor Unit |
KSCC-12CHW KSCC-12CHW/W |
KSCC-18CHW KSCC-18CHW/W |
KSCC-24CHW |
KSCC-36CHW KSCC-36CHW/W |
|---|---|---|---|---|---|
| Performance | |||||
| Cooling Capacity | BTU/h | 12,000 | 18,000 | 24,000 | 36,000 |
| KJ/h | 12,660 | 18,990 | 25,320 | 37,980 | |
| Water Flow | L/S | 0.15 | 0.23 | 0.3 | 0.45 |
| Air Flow | m3/h (CFM) | 1,100 (647) | 1,100 (647) | 1,100 (647) | 1,500 (882) |
| Sound Level | dB(A) | 42 | 42 | 42 | 45 |
| Running Current | Amps | 1 | 1 | 1 | 1.9 |
| Rated External Static Pressure | Pa | 0 | 0 | 0 | 0 |
| Power Supply | V/Ph/Hz | 230V / 60 |
230V / 60 |
230V / 60 |
230V / 60 |
| Unit | |||||
| Dimension (WxDxH) | mm | 1,000 x 542 x 261 | 1,000 x 542 x 261 | 1,000 x 542 x 261 | 1,100 x 598 x 330 |
| Packaging Dimension (WxDxH) | mm | 1,077 x 625 x 351 | 1,077 x 625 x 351 | 1,077 x 625 x 351 | 1,177 x 682 x 420 |
| Weight (Net/Gross) | kg | 31 / 37 | 33 / 39 | 34 / 40 | 47 / 53 |
| Pipe Connection Diameter | mm (inch) | 19.05 (3/4) | 19.05 (3/4) | 19.05 (3/4) | 19.05 (3/4) |
