| Specification |
Indoor Unit Outdoor Unit |
KSCC-36C KPC-36IH0C1 |
KSCC-60R3DA KPC-60JV3DA |
|---|---|---|---|
| Cooling Capacity | TR | 3.0 | 5.0 |
| BTU/Hr | 36,000 | 53,000 | |
| kJ/Hr | 37,980 | 55,915 | |
| Power Supply | V/Ph/Hz | 230 /60 |
230/3 /60+N+G |
| Rated Power | W | 3,980 | 6,350 |
| Rated Current | A | 17.40 | 19.3 |
| EER | BTU/W-Hr | 9.04 | 8.35 |
| kJ/W-Hr | 9.54 | 8.81 | |
| CSPF | — | 2.60 | |
| Refrigerant | R410A | R410A | |
| Operation Temperature (Min-Max) | °C | 17-30 | 17-30 |
| Applicable Area (Unloaded Space) | SQM | 42-66 | 53-93 |
| Airflow Volume Hi | CMH | 1,500 | 2,604 |
| Noise Level Hi/Mi/Low | dB(A) | — | 52/49/46.6 |
| Indoor | |||
| Unit Dimension (W×D×H) | mm | 1,100×598×330 | 1,200×874×300 |
| Packaging Dimension (W×D×H) | mm | 1,177×682×420 | 1,405×915×365 |
| Unit Weight (Net/Gross) | kg | 48/52 | 48.6/57.9 |
| Outdoor | |||
| Unit Dimension (W×D×H) | mm | 936×355×812 | 710×710×843 |
| Packaging Dimension (W×D×H) | mm | 1,079×499×854 | 738×738×872 |
| Unit Weight (Net/Gross) | kg | 72/76 | 78.2/82.8 |
| Piping Connections | |||
| Liquid Pipe Size (Diameter) | mm (in) | Ø9.53 (Ø3/8) | Ø9.52 (Ø3/8) |
| Gas Pipe Size (Diameter) | mm (in) | Ø15.88 (Ø5/8) | Ø19.05 (Ø3/4) |
| Max. Refrigerant Pipe Length | m | 30 | 50 |
| Max. Difference in Level | m | 8 | 30 |
